節能燃?xì)庹羝仩t結構特點

節能燃?xì)庹羝仩t采用波形爐膽，既強化了煙氣的擾動，又增大了輻射傳熱面積；既增加了爐膽的強度，又有效的減弱了爐膽的膨脹應力；既增強傳熱效果，又促進了燃料在爐膛內的燃燒。

節能燃?xì)庹羝仩t煙道尾部增設冷凝器，利用冷凝器吸收煙氣中的潛熱和顯熱，提高了鍋爐的進水溫度，降低了排煙溫度，使鍋爐的熱效率提高到98%以上。（備注：鍋爐使用過程中冷凝器進出水閥門必須常開）

A undee hearth of a form  A undee hearth of a form of this series boiler ,enhanced the moving of smoke,and then enlarged the radiation area,to transmit heat by this area,to transmit heat by this area,increased a undee hearth intensity,and effectively weaken the internal force of a undee hearth;to build up transmits heat the result,and then promoted.

Rear flueadditional condenser  Additional rear flue condenser using flue gas condenser absorbs latent heat and sensible heat,improving the water temperature of the boiler,reducing the exhaust gas temperature ,the thermal efficiency of the boiler increased to more than 98%.(Note:The process of using the boiler,condenser out of the water valve must be normally open)
